Inverter – Wi-Fi Ready

Brand: Aux

Model: MASDC12QGR1

Capacity: 12000BTU

Color: White

Cooling:

• • Rated Capacity: 3500W (800 – 4000W)
  • Rated Power Consumption: 1180W (400 – 1600W)
  • Rated Running Current: 5.6A (1.7 – 7.1A)

Max. Input Power: 1600W

Max. Input Current: 8A

EER Cooling: 2.97 W/W

EU Energy Rating: A++

Power Supply Source: 220 ~ 240V – 1Ph – 50Hz

Refrigerant: R32

Refrigerant charged: 400g

Max. Discharge Pressure: 4.3 Mpa

Max. Suction Pressure: 2.5 Mpa

Air Flow Volume: 600 m3/h

Warranty: 1 Year Warranty plus 5 Years Compressor Warranty

 Indoor Unit:

Indoor Noise Level: 41 dB(A)

Evaporator:

• • Rows: 2
  • Tube pitch: 19.05
  • Tube Material: screws inside
  • Tube Thickness: 0.2mm
  • Tube Quantity: 16
  • Fin Material: hydrophilic foil
  • Fin Type: window
  • Fin Thickness: 0.094mm
  • Fin spacing: 1.3mm

Fan System:

• • Type: Crossflow
  • Material: AS

Connect pipe (length): 3m

Stop Valve:

• • Liquid valve: 0.25
  • Gas valve: 0.375

 Outdoor Unit:

Outdoor Noise Level: 52 dB(A)

Type: Rotary

Fan:

• • Type: Axis flow
  • Vane Number: 3
  • Blade Material: AS

Motor: D-20-10A

Condenser:

• • Row: 1
  • Tube Material: screws inside
  • Tube Quantity: 11
  • Fin Material: hydrophilic foil
  • Fin Type: window
  • Fin spacing: 1.3mm

Dimension & Weight:

Width x Depth x Height

Indoor Unit:

• • Product Dimension: 761 x 200 x 295mm (30” x 7.9” x 11.6”)
  • Packing Dimension: 825 x 277 x 367mm (32.5” x 10.9” x 14.4”)
  • Net Weight: 8kg
  • Gross Weight: 11kg

Outdoor Unit:

• • Product Dimension: 703 x 260 x 456mm (27.7” x 10.2” x 18”)
  • Packing Dimension: 760 x 305 x 510mm (29.9” x 12” x 20.1”)
  • Net Weight: 17kg
  • Gross Weight: 20.5kg

Packing Contents:

12k BTU Indoor Unit – x1

• • Remote Control – x1
  • Remote Holder (Wall-Mount) – x1
  • Screws with Plugs – x2
  • AA Battery – x2
  • Electric Wire – x1
  • Drainage Hose – x1
  • User Manual – x1

12k BTU Outdoor Unit – x1

• • 1/4″ Insulated Copper Tube – x1
  • 3/8” Insulated Copper Tube – x1
  • Clay – x1
  • Wall Hole Cover – x1
  • Wrapping Roll – x1
